The excellent GBM 4/50 SGA model offers numerous useful functions for high-quality and economical drilling and threading.Automatic height adjustment of the work table from the working position and an automatic tool ejector ensure reduced changeover time. 12 speed levels up to 2,050 rpm and automatic feed with four stages provide consistently appropriate cutting speeds - drilling capacity in steel up to Ø 50 mm.Integrated cooling system, and a threading function with reverse rotation on the feed lever, complete the entire scope of this top model drilling machine. Additional advantages: with a digital depth display, you can also make holes and threads with narrow depth tolerances.* Drill spindle with precision bearings* Rotation to the right and left* Thread cutting function with reversing rotation using switches on the control handle* 4 automatic feeds 0.07 / 0.15 / 0.26 / 0.4 mm/rev* Digital drilling depth display* Automatic tool ejector* Precision drill table and base plate with T-slots and emulsion channel* Automatic height adjustment of the drill table with worm gear* Integrated cooling system with return flow and tank in the machine base* Protection of the drilling tool* Depth scale with stop* Halogen lighting of the work tableSpecificationsTaper in quill: MK-4Speed range (rpm): 42-2050Number of levels: 12Drilling stroke: 180T-slots/width (mm): 14Drill table stroke (mm): 540Overhang (mm): 360Drill table tilt: +-90°Drill table rotation: +- 180°Distance from quill to table (mm): 60-600Distance from quill to base (m): 1215Table size (mm): 505×375Motor power (W): 2800/2200Emulsion pump (W): 90Connection (V/Hz): 400/50-60Emulsion pump flow rate (l/min): 6Automatic quill feed (mm/rev): 0.07/0.15/0.4Number of quill feed stages: 4Cube dimensions (mm): 505x375x600Height (mm): 2320Weight (kg): 740

The drill machine GBM 4/40 SGA belongs to the group of premium ELMAG® high-quality drilling machines, as it combines the most modern technique of drilling gear systems. The machine is equipped as standard with an automatic feed system for the quill and an integrated cooling system with a return water flow. Additional functions offered to the user include thread cutting with reverse rotation, automatic tool ejector, and display of operation status.With 12 speed levels from 70 to 2,600 RPM, the GBM 4/40 SGA model enables drilling in steel up to 40 mm. Thanks to its precise and robust design, it is suitable for both individual drillings in a locksmith's workshop or tool shop, as well as in serial production.* Drilling spindle with precision bearings* Right and left rotation* Thread cutting function, reverse rotation switch on the feed handle buttons* Automatic quill feed, 3-stage 0.1 / 0.2 / 0.3 mm/R* Automatic tool ejector* Precision drilling table and base plate with T-slots and an emulsion channel* Integrated cooling system with return water, tank in the machine base* Adjustable drill guard* Drilling depth scale with a stop* Halogen work lamp* Standard equipment: drill chuck, drill chuck taper, reducing sleeves, ejector wedge, handy toolsSpecificationsQuill taper: MK-4Speed range (RPM): 70-2600Number of stages: 12Drilling stroke: 150T-slots/width (mm): 14Drilling table stroke (mm): 550Overhang (mm): 325Drilling table - tilt: +-90°Drilling table - swivel: +- 180°Distance from quill to table (mm): 45-600Distance from quill to base (m): 1150Table size (mm): 424×424Motor power (W): 2200/1500Emulsion pump (W): 90Connection (V/Hz): 400/50-60Emulsion pump flow (l/min): 6Automatic quill feed (mm/v): 0.1/0.2/0.3Number of quill feed stages: 3Volume (mm): 424x424x600Height (mm): 2230Weight (kg): 670

standard equipment* drill head 1-16 mm with MK3/B16 taper adapter* reducing sleeves MK3/MK2 and MK3/MK1* knockout wedgeThe robust column model GBM 3/30 SNA has automatic quill feed and is equippedwith a robust special gearbox, has a drilling capacity in steel of 30 mmand provides up to 810 mm height of quill above the table, offering enough space for machining tall workpieces.The gearbox with helical gears made from a combination of steel and special pressed material ensures the overcoming of heavy loads and smooth running.The GBM 3/30 SNA drill machine is thus an excellent solution for medium-heavy demands in construction and locksmithing, even in small batch production.* Large working height, high revolutions.* Automatic quill feed* Digital scale for drilling depth* Machined base plate under the stand* Two-stage motor* four feed speeds (0.1/0.15/0.22/0.3 mm/r)* MK3 quill taperTaper in quill: MK-3Speed range (RPM): 75-3010Number of stages: 8Drilling stroke: 150T-slots/width (mm): 14Drill head travel (mm): 270Drill table travel (mm): 500Overhang (mm): 320Drill head - rotatable: +- 180°Drill table - rotatable: +- 180°Distance quill to the table (mm): 50-820Table size (mm): 500×350Motor power (W): 1200/900Connection (V/Hz): 400/50Automatic quill feed (mm/rpm): 0.1 / 0.15 / 0.22 / 0.33Number of quill feed stages: 4Volume (mm): 500x350x870Height (mm): 1840Weight (kg): 290

Standard equipment* Self-tightening drill chuck 1-16 mm / B16* Drill chuck arbor MK3/B16* Reducing sleeve MK 3 / MK 2* Reducing sleeve MK 3 / MK 1* Drift keyThe robust column model GBM 3/25 SNE is equipped with a robust special gear, has a steel drilling capacity of 25 mm, and offers up to 840 mm quill height above the table for processing tall workpieces. The helical gear transmission is made with a combination ofsteel and special pressed materials, ensuring the machine can handle high loads and provide smooth operation.The GBM 3/25 SNE drilling machine is an excellent solution for medium-heavy requirements in construction and locksmithing, even for small batch production.* Drilling capacity Ø 25 mm* Volume 500 x 350 x 840 mm* Overhang 255 mm* Powerful drive motor 400 V,* 2-speed 900 / 650 W* Quality smooth-running gear with helical gearing for high-load capabilities* 8 speed levels 105 - 2,900 RPM* Drilling spindle with precise bearings* Right and left rotation* Drilling spindle with protection* Depth gauge and stop* Tool ejector* Digital depth gauge* Precisely machined drill table with T-slots and emulsion channel* Swivel and height adjustable drill head* Robust and ground steel column with rack* Emergency STOP button / undervoltage protectionQuill taper: MK-3Speed range (RPM): 105-2900Number of speeds: 8Drilling stroke: 120T-guide/width (mm): 14Drill head stroke (mm): 580Drill table stroke (mm): 530Overhang (mm): 255Drill head - rotating: +- 180°Drill table - rotating: +- 180°Distance from spindle to table (mm): 0-840Table size (mm): 500×350Motor power (W): 900 / 650Connection (V/Hz): 400/50-60Dimensions (mm): 500x350x840Height (mm): 1760

Standard equipment* Self-tightening drill chuck 1-16 mm / B16* Drill chuck arbor MK3/B16* Reducing sleeve MK 3 / MK 2* Reducing sleeve MK 3 / MK 1* Ejector wedgeIdeal machine for small-batch productionIf it is necessary to machine hard or tough steels and stainless steels, it makes sense to opt for a powerful geared drill machine.Thanks to the gearbox with a combination of steel and special pressed material gears, the operation of the powerful GBM 3/25 TNE drill machine is particularlysmooth. With a speed of up to 2,900 RPM, an ideal cutting speed is available for small boreholes. For threading, the machine is equipped with both clockwise and counterclockwise rotation.* Digital drilling depth scale* Drill spindle with precision bearings* Clockwise and counterclockwise rotation* Drill spindle with protection* Depth measurement scale and stop* Tool ejector* Precisely machined drill table with T-slots and emulsion channel* Rotatable and height-adjustable drill head* Robust and ground steel column with gear rack* Emergency STOP button / undervoltage protection with S 5 meter supply cable and EURO - CEE protective plug 16 AmpereQuill taper: MK-3Speed range (RPM): 105-2900Number of steps: 8Drilling stroke: 120T-slots/width (mm): 14Drill head stroke (mm): 580Overhang (mm): 255Drill head - rotatable: +- 180°Distance from quill to table (mm): 0-580Table size (mm): 290×250Motor power (W): 900 / 650Connection (V/Hz): 400/50-60Cubature (mm): 290x250x580Height (mm): 1150Weight (kg): 130

STRANDS MODEL S 40 - Drilling capacity steel: 40 mm - Overhang: 330 mm - Floor-standing design

STRANDS MODEL S 40 M - Feed: 0.10 / 0.16 / 0.24 / 0.33 mm/rev - Drilling capacity in steel: 40 mm - Overhang: 330 mm - Free-standing design

STRANDS MODEL S 40 ME - Feed: 0.10 / 0.16 / 0.24 / 0.33 mm/rev - Drilling capacity in steel: 40 mm - Overhang: 330 mm - Free-standing design

STRANDS MODEL S 35 - Drilling capacity in steel: 35 mm - Swing: 320 mm - Floor-standing design

STRANDS MODEL S 35 ME Feed: 0.10 / 0.15 / 0.22 / 0.30 mm/rev Drilling capacity in steel: 35 mm Overhang: 320 mm Free-standing design

STRANDS MODEL S 35 M - Feed: 0.10 / 0.15 / 0.22 / 0.30 mm/rev - Drilling capacity in steel: 35 mm - Overhang: 320 mm - Free-standing design

STRANDS MODEL S 30BM - Feed: 0.10 / 0.15 / 0.22 / 0.30 mm/rev - Drilling capacity in steel: 30 mm - Throat depth: 320 mm - Bench drilling machine

STRANDS MODEL S 40 ME - Feed: 0.10 / 0.16 / 0.24 / 0.33 mm/rev - Drilling capacity in steel: 40 mm - Overhang: 330 mm - Free-standing design

STRANDS MODEL S 30M - Feed: 0.10 / 0.15 / 0.22 / 0.30 mm/rev - Drilling capacity steel: 30 mm - Overhang: 320 mm

Drilling capacity: 60 mm Thread capacity: M36 Taper in quill: MK 5 Revolutions: 50 - 2000 rpm

STRANDS MODEL S 35 - Drilling capacity in steel: 35 mm - Swing: 320 mm - Floor-standing design

STRANDS MODEL S 25 B - Drilling capacity in steel: 25 mm - Overhang: 255 mm - Bench drill press

Drilling capacity: 50 mm Threading capacity: M24 Taper in spindle: MK 4 Speeds: 42 - 2050 rpm

STRANDS MODEL S 35 ME Feed: 0.10 / 0.15 / 0.22 / 0.30 mm/rev Drilling capacity in steel: 35 mm Overhang: 320 mm Free-standing design

- Drilling capacity: 25 mm - Thread capacity: M16 - Taper in spindle: MK 3 - Speed: 150 - 2900 rpm

Elmag KSBM 5/63 - Feed: 0.1 - 0.78 mm/rev - Drilling capacity in steel: 63 mm - Overhang: 375 mm

Drilling capacity: 40 mm Threading capacity: M16 Spindle taper: MK 4 Rotation speed: 75 - 960 / 170 - 16000 rpm

STRANDS MODEL S 25 - Stepless speed adjustment - Drilling capacity steel: 25 mm - Overhang: 255 mm - Bench drill press

Drilling capacity: 25 mm Threading capacity: M16 Taper in spindle: MK 3 Revolutions: 150 - 2900 rpm
