Sanding belt: 150 x 2000 mm Sanding speeds 2: 14.5 / 29 m/s Drive motor: 4000 W

Now FREE: 7-piece set of sanding rollers fi 20 / 28 / 32 / 42 / 48 / 60 / 70 RADIUS GRINDING ON PIPES AND PROFILES RSM belt grinder for radiuses allows precise grinding of radiuses to create proper fits and angles in the joining of pipes, profiles, axes,… Ideal tool for bending profiles, installations, pipelines, fences, machine construction,… The machine can also be used as a classic belt grinder for edge deburring, bevels, shapes and contours, flat grinding, and surface finishing. - Quick clamping and releasing of workpieces with sliding adjusting lever and quick-clamping lever - precise guiding of the workpieces - longitudinal guiding with the help of guiding sled and feeding lever, transverse movement with transverse sled with lever - easy angle adjustment for grinding with angle vice and scale on transverse sled - smooth operation without vibrations - balanced drive wheel and contact axes, mounted in precision bearings - easy replacement of contact wheels and sanding belt with belt tensioner - use for deburring, flat grinding on the upper side of the belt via a lifting cover - powerful drive motor 3,000 W, 400 V - high sanding power - belt speed 30 m/s - safe operation - robust steel housing, protective cover, spark protection, eye protective glass, emergency STOP button, undervoltage protection, CE-compliant Machine features: ELMAG RSM radius grinders for precise grinding with radius Standalone design Belt speed is not adjustable Intended for construction or machine engineering Quick and easy belt replacement Built-in extraction connection Robust metal housing Technical data:   RSM 100x2000 Sanding belt width 100 mm Grinding surface 100x400 mm Belt length 2000 mm Belt speed 30 m/s Motor power 3000 W Voltage 400V Machine dimensions 1400x800x1160 mm Weight 145 kg

The combined belt and disc sander is the right tool for a variety of detailed work on all materials.Its powerful and quietly operating induction motor with a power of 370 W ensures operation with minimal vibrations.The adjustable work table and sanding belt, which can be set at an angle of 90 degrees, offer numerous usage possibilities.The sanding belt is adjustable both horizontally and vertically.Its solid construction allows for sufficient pressure for consistently accurate sanding results.The sanding disc with velcro fastener allows easy and quick changing of sanding paper.Standard equipment- Adjustable sanding base on the left side- Adjustable sanding base on the right side- Sanding belt with grain size 80- Balanced guide wheel- Tensioning handle for the belt- Guide track for belt sliding- Support table 0–45°- Zero voltage switch-off* sanding belt dimension: 100×950 mm* sanding disc diameter: 150 mm* motor: 370 W, 230 V / 50 Hz* sanding belt speed: 7.3 m/s* number of revolutions of the sanding disc: 2,850 rpm* table dimension: 225×160 mm* worktable adjustment: 0-45°* belt arm adjustment: 0-90°* velcro for sanding disc: yes* extraction connection: 63 mm* machine dimension: 340x290x320 mm* weight: 6.5 kg

Sanding belt: 150 x 2000 mm Sanding speeds 2: 14.5 / 29 m/s Drive motor: 4000 W

Now FREE: 7-piece set of sanding rollers fi 20 / 28 / 32 / 42 / 48 / 60 / 70 RADIUS GRINDING ON PIPES AND PROFILES RSM belt grinder for radiuses allows precise grinding of radiuses to create proper fits and angles in the joining of pipes, profiles, axes,… Ideal tool for bending profiles, installations, pipelines, fences, machine construction,… The machine can also be used as a classic belt grinder for edge deburring, bevels, shapes and contours, flat grinding, and surface finishing. - Quick clamping and releasing of workpieces with sliding adjusting lever and quick-clamping lever - precise guiding of the workpieces - longitudinal guiding with the help of guiding sled and feeding lever, transverse movement with transverse sled with lever - easy angle adjustment for grinding with angle vice and scale on transverse sled - smooth operation without vibrations - balanced drive wheel and contact axes, mounted in precision bearings - easy replacement of contact wheels and sanding belt with belt tensioner - use for deburring, flat grinding on the upper side of the belt via a lifting cover - powerful drive motor 3,000 W, 400 V - high sanding power - belt speed 30 m/s - safe operation - robust steel housing, protective cover, spark protection, eye protective glass, emergency STOP button, undervoltage protection, CE-compliant Machine features: ELMAG RSM radius grinders for precise grinding with radius Standalone design Belt speed is not adjustable Intended for construction or machine engineering Quick and easy belt replacement Built-in extraction connection Robust metal housing Technical data:   RSM 100x2000 Sanding belt width 100 mm Grinding surface 100x400 mm Belt length 2000 mm Belt speed 30 m/s Motor power 3000 W Voltage 400V Machine dimensions 1400x800x1160 mm Weight 145 kg

The combined belt and disc sander is the right tool for a variety of detailed work on all materials.Its powerful and quietly operating induction motor with a power of 370 W ensures operation with minimal vibrations.The adjustable work table and sanding belt, which can be set at an angle of 90 degrees, offer numerous usage possibilities.The sanding belt is adjustable both horizontally and vertically.Its solid construction allows for sufficient pressure for consistently accurate sanding results.The sanding disc with velcro fastener allows easy and quick changing of sanding paper.Standard equipment- Adjustable sanding base on the left side- Adjustable sanding base on the right side- Sanding belt with grain size 80- Balanced guide wheel- Tensioning handle for the belt- Guide track for belt sliding- Support table 0–45°- Zero voltage switch-off* sanding belt dimension: 100×950 mm* sanding disc diameter: 150 mm* motor: 370 W, 230 V / 50 Hz* sanding belt speed: 7.3 m/s* number of revolutions of the sanding disc: 2,850 rpm* table dimension: 225×160 mm* worktable adjustment: 0-45°* belt arm adjustment: 0-90°* velcro for sanding disc: yes* extraction connection: 63 mm* machine dimension: 340x290x320 mm* weight: 6.5 kg
